High End Reject Conveyor 460mm 1000mm Touch/VT-Net

Part No.: VT-TBRW-460-1000-020

Category: High Version Reject Conveyor

The unit installed after AOI for separated NG board for visual inspect and good board will pass through without stopping.

Description & Technical data

Standard features

PLC Program control
Start / Stop push button
Anti-static conveyor belt
Centre PCB stop position
Easy way of belt replacement
Reject and by-pass mode selectable
Heavy bottom design to prevent shifting
PCB precise stopping in position
Smooth and parallel width adjustment.(lead screw)
SMEMA compatible

Options

Non standard conveyor / segment lengths
Alarm buzzer
SMEMA cable(1.5m or specify)
Light fixture
Additional lift positions for extra buffer capacity
Other options available on request

Condition:	Demo Unit
Year of Manufacturing:	2017
Operation:	Touch Screen
Width Adjustment:	Automatic
PCB Edge Support:	3mm Flatbelt
Max PCB Width:	460mm
Max PCB Lenght:	530mm
Option Tower Light:	Yes
Communication:	SMEMA
Transfer Direction:	Left to Right
